UPA1830GR-9JG - P-CHANNEL MOS FIELD EFFECT TRANSISTOR FOR SWITCHING - NEC Datasheet

DESCRIPTION
The µPA1830 is a switching device which can be driven directly by a 4.0 V power source.
This device features a low on-state resistance and excellent switching characteristics, and is suitable for applications such as power management of notebook computers and so on.

FEATURES
• 4.0 V drive available
• Low on-state resistance
    RDS(on)1 = 17 mΩ MAX. (VGS = −10 V, ID = −4.5 A)
    RDS(on)2 = 24.5 mΩ MAX. (VGS = −4.5 V, ID = −4.5 A)
    RDS(on)3 = 28 mΩ MAX. (VGS = −4.0 V, ID = −4.5 A)
• Built-in G-S protection diode against ESD
